2x2 Optical Coupler , Compact Fiber Optic Coupler Low Insertion Loss For Communication Network

Name: 2x2 Optical Coupler Compact Fiber Optic Coupler Low Insertion Loss For Communication Network
Brand: Gracyfiber
Price: 1 USD

Quality 2x2 Optical Coupler , Compact Fiber Optic Coupler Low Insertion Loss For Communication Network for sale

Place of Origin : Guangdong , China

Brand Name : Gracyfiber

Certification : ISO9001 , ROHS

MOQ : 1pieces

Payment Terms : L/C,T/T

Delivery Time : 5-8 work days

Supply Ability : 100,000 pieces per month

Name : 2x2 Optical Coupler

Fiber Type : 1

Insertion Loss : ≤ 0.2 dB

Cable Compatibility : Single-mode and multi-mode fibers

Operating Wavelength : 1260 nm to 1650 nm

Operating Temperature : -40°C to +85°C

Return Loss : ≥ 50 dB

Contact Now

2x2 Optical Coupler Fiber Optic Coupler Low Insertion Loss Wide Wavelength Range Optical Fiber Splitter For Fiber Communication Network And Sensing

Product Overview

This 2x2 compact fiber optic coupler is designed for high-precision optical signal distribution and transmission.

Key Features

2x2 High-Precision Optical Signal Distribution Architecture
Insertion Loss ≤ 0.2 dB
Return Loss ≥ 50 dB
Wide Operating Wavelength Range: 1260nm - 1650nm
Compatible with Single-Mode and Multimode Fiber Systems
Industrial-Grade Wide Temperature Range: -40°C to +85°C
Compact Design for Easy High-Density Device Integration

Applications

Fiber Optic Communication and Backbone Networks
Optical Signal Distribution and Network Expansion Architectures
Fiber Optic Sensing and Signal Acquisition Systems
High-Precision Optical Test and Measurement Equipment
High-Speed, High-Capacity Optical Signal Multiplexing Systems

2x2 Optical Coupler , Compact Fiber Optic Coupler Low Insertion Loss For Communication Network

FAQ

1. How do the insertion loss (IL) and optical performance of this product perform?

Low insertion loss is the core advantage of this product. We use a mature fused biconical taper (FBT) process and conduct 100% rigorous optical testing before shipment. The product not only boasts extremely low insertion loss but also ultra-low polarization dependent loss (PDL) and high directivity, ensuring extremely high fidelity of optical signals during power distribution or convergence.

2. What is the operating temperature range of the coupler? Can the compact design meet the needs of high-density cabling?

This coupler uses industrial-grade packaging technology, supporting a wide operating and storage environment from -40°C to +85°C, unaffected by harsh outdoor or data center temperature fluctuations. Furthermore, its extremely compact steel tube or miniaturized ABS box packaging design is ideal for installation in space-constrained fiber optic closures or high-density distribution frames (ODFs).

3. Do you support non-standard splitting ratios and custom interfaces (OEM/ODM)?

Fully supported. As a professional source manufacturer, we can provide custom splitting ratios from 1:99 to 50:50 according to your specific link power budget requirements. Furthermore, we can quickly provide drawings and prototyping services for specific bare fiber lengths, outer jacket diameters (250μm/900μm/2.0mm/3.0mm), and different types of connectors (APC/UPC) such as SC, LC, and FC.
